Power Tug ™
The Power Tug™ is a battery-powered tugger designed to promote productivity with minimal manpower by mobilizing up to 6,000 pounds with ease. The Power Tug has a mono-drive wheel with a stabilizing swivel caster that enables the unit to mobilize loads over uneven surfaces with complete control. The tugger body, equipped with an electric actuator, accommodates various load heights.
Power Tug ™
Click Below To
See It In Action!
Specifications & Dimensions
The Power Tug™ offers:
- Motor: 24 volt D.C. – 600W (2,500 lb. capacity), or 1200W (6,000 lb. capacity).
- Drive Mechanism: Planetary Gearbox, 18:1 reduction, through mono-drive wheel.
- Controller: Fully programmable digital, with diagnostic capability, four quadrant full bridge power output stage.
- Batteries: 2 x 60 Amp/hour dry fit, gel type sealed & maintenance free.
- Battery Charger: On-Board, 3 stage 2 x 10 Amp circuits (110v or 240v input).
- Push/Pull Capacity: Up to 6,000 lbs. (Subject to rolling resistance of load).
- The battery-powered tugger includes a 24-volt DC, 600-watt motor for 2,500-pound push/pull capacity or a 1200-watt motor for 6,000-pound push/pull capacity
- Mono-drive wheel for stable performance on uneven surfaces
- Fingertip controls for operator convenience and ease-of-use
- On-board charger for long-lasting, efficient operation
- Automatic braking and emergency reverse protection improves operator safety
- Fully programmable control system with diagnostic features to adjust speed and acceleration/deceleration based on load and environment
- Ergonomic handles for operator comfort
- Compact size for easy maneuverability of the battery-powered tug
- Polyurethane drive wheel outer with alternative tread patterns and material specifications
48” H x 55.50” L x 24.5” W
- Audible motion beeper
- Safety strobe
- Dual leg configuration
- Custom Attachments Available
Common Questions About The Power Tug ™
Are you thinking about adding the PowerTug to your workflow? Contact us with any questions that you may have, or review some of the commonly asked questions that our sales team receives below:
The capacity of PowerPusher equipment is based on many variables. For this reason, we have set up a talented team to help guide you through the selection process. Fill out our Contact Form or call us at 281-256-7450 for more information.
Yes, the PowerPusher equipment can push and pull.
The demo program is 2 weeks long.
No, our electric pushers and tugs use regular deep-cycle marine batteries.
None of our machines require a license to operate. Further, most anyone can learn to operate proficiently with very minimal training.
Yes, they are made in Shakopee, Minnesota.
